 | Agfa Avantra 44
Imagesetter, Buffer, Bridge & Processor |
|
Image Area: 35.5" x 44" Format |
|
Resolution/Spot Size: 1200/20u,
1800/15u, 2400/9.5u, 3600/8.0u |
|
Repeatability: +/- 0.5 mils |
|
|
Density Range: 3.8D to 4.2D |
|
Density Variation: .2D Deviation |
|
Dot Gain: 2% Deviation |
|
|
Line Screens: Up to 300LPi |
|
Media Width: User definable form 16" to 36"
film or plate |
| Agfa Avantra 30 Imagesetter, Buffer, Bridge &
Processor |
|
Image Area: 29.5" x 25" |
|
|
|
Media Transport Technology: Internal Drum |
|
|
Laser Technology: Visible Red Laser Diode Film |
|
|
Head and Tail Punch System: Setup in
Stoesser Configuration |
|
|
Selectable Resolution's: 1200,
1800, 2400, 3600 |
|
|
Spot Size: 7.5u @ 3600DPI, 10u @ 2400DPI, 20u @ 1200DPI |
|
|
Repeatability: +/- 0.0015 Mil |
|
|
|
Line Screens: 250+ |
|
|
|
Agfa Avantra 25 Imagesetter |
|
Max
Image Area: 17.7 x 25 |
|
|
Laser: Red Diode 650NM |
|
Resolution: 1200,1800,2400,3600 |
|
|
Spot Size: 20,15,10,7.5u |
|
|
Repeatability: +/- .2Mil over 8 Seps |
|
Media: Visible Red Laser Diode Film |
|
Includes: Take-up & Supply
Punches, Opti-Spot |
| Agfa SelectSet 7000 Imagesetter |
|
Image Area: 25.69" x 22" |
|
Media Transport Technology: Internal Drum |
|
Laser Technology: Helium Neon |
|
Selectable Resolution's: 1200,
2400, 3600 |
|
Spot Size: 7.5u @ 3600Dpi, 10u @ 2400DPI, 20u @ 1200DPI |
|
Repeatability: +/- 0.0015 Mil |
|
Line Screens: 250+ |
|
| Agfa Accuset 1000 Imagesetter |
|
Image Area: 14" Width ,
14" x 24" over 6 Seps |
|
Resolution: 600, 1200, 1800, 2400, 3000 |
|
Media: Visible Red Laser Diode (VRL-Film) |
|
Repeatability: +/- 1Mil Typical |
|
